Passenger lift

Symbio large loads

Machine room-less Symbio Lift prepared for large loads with roping 4:1.

Advantages

Comfort:
Roping 4:1 with pulleys under the car frame, providing excellent stability and great comfort.

Optimization:
Self-supporting bed plate and pulley beam prepared to adapt to the shaft.

Adaptability:
Possibility of anti-creep for high specific loads.

Symbio large loads

Applications

  • Shopping Centers
  • Hotels
  • Hospitals
  • Offices
  • Large loads

Technical Features

Duty speed: 0,5 m/s being able to reach up to 1 m/s
Duty load: 4.800 kg.
P+Q: 8.000 kg
Ropes: 10 mm.
Roping: 4:1
Standart headroom: 4.500 mm.
Minimum headroom: 4.200 mm.

Manufacturers

Car Frame: TTV
Machines: SICOR, CEG, ZIEHL-ABEGG, SASSI
Doors: FERMATOR, WITTUR, MEILLER
Control panel: CARLOS SILVA, SPRINTE, NEWLIFT, DIGITAL ADVANCE, ARKEL, LESTER
Pushbuttons: BST, SCHAEFER, DEWHURST

Downloads

Catalog sheet
