Car Lift

Parkinglift

Hydraulic lift for vehicles in compliance with the Lifts Directive.

Avantages

Security:
In the event of an electrical failure, the car descends to the next stop facilitating the exit of the vehicle and the opening of the doors (optional).

Easy installation:
The design is oriented to a reduction of assembly hours.

Stability:
It has cabin braces, providing more rigidity and stability.

Parking assistance system:
Easy vehicle positioning with light curtain. In the upper part of the door, the display indicate whether the vehicle is correctly positioned (optional).

Certificate

We have a deviation from Standard for the Parking Lift that allows us to optimize the whole of the car lifts for the loads used.

Deviation from standard for surface greater than table 6 in the EN 81.20 standard

Parkinglift

Applications

  • Vehicles
  • Residential buildings

Technical Features

Duty speed: Up to 0,5 m/s
Duty load: Up to 5500 kg.
Roping: 2:1
Standard pit: 1200 mm.
Standard headroom: 3600 mm.

Manufacturers

Car Frame: EMESA
Hydraulic equipment: GMV, MORIS, BUCHER
Doors: FERMATOR, WITTUR, MEILLER
Control Panel: CARLOS SILVA, SPRINTE, NEWLIFT, DIGITAL ADVANCE, ARKEL, LESTER MEGOM
Pushbuttons : BST, SCHAEFER, DEWHURST
