Passenger lift

Hydronic

Hydronic is the ideal hydraulic lift for existing buildings, capable of adapting to any kind of shaft.

Advantages

Versatility:
We adapt each lift to each different shaft optimizing spaces.

Reduced pit and headroom:
In existing buildings, we adapt our lifts in compliance with the Regulations for pit and headroom. (EN 81.21).

Comfort:
Excellent level of comfort, equivalent to a traction lift using electronic valves.

Adaptability:
Easy control and maintenance.

Emergency rescue:
Automatic emergency system always active during the descent, even in the event of power failure.

Hydronic

Applications

  • Residential buildings
  • Modernizations
  • Existing shafts
  • Refurbishment
  • Reduced shafts

Technical Features

Duty speed: 0,63 m/s (Option Up to 1 m/s)
Duty load: Up to 1800 kg.
Standard pit: 1200 mm.
Standard headroom: 3500 mm.
Travel: Up to 25m.
Other options: Cabinets

Manufacturers

Car Frame: EMESA
Hydraulic equipment: GMV, MORIS, BUCHER
Doors: FERMATOR, WITTUR, MEILLER
Control panel: CARLOS SILVA, SPRINTE, NEWLIFT, DIGITAL ADVANCE, ARKEL, LESTER, MEGOM
Pushbuttons: BST, SCHAEFER, DEWHURST

Downloads

Catalogue sheet

Customised solutions

Panoramic

Hydronic

Irregular shaft

Hydronic
Hydronic

Borehole piston

Hydronic
Hydronic
